- Swing-bucket rotors and adapters accommodate tubes and bottles from 0.2 mL to 250 mL
- Plate rotor for centrifugation of all types of MTP, PCR, cell culture, or Deepwell Plates
- Fixed-angle rotors for high-speed applications in tubes from 0.2 mL to 85 mL
- High centrifugation speed of up to 20,913 × g (14,000 rpm)
- Centrifuge lid with soft-touch lid closure
- Low access height of 29 cm for easy loading and unloading of samples
- Quiet operation to improve your work environment
- Compact footprint saves valuable bench space
- Automatic rotor recognition and imbalance detection for maximum operational safety
| Specifications | 5804 |
|---|
| Max. RCF | 20913 × g |
| Max. RCF with fixed-angle rotor | 20913 × g |
| Max. RCF with swing-bucket rotor | 4500 × g |
| Max. RCF with plate rotor | 2250 × g |
| Speed | 200 – 14,000 rpm (10 rpm steps) |
| Product type | Centrifuges |
| Rotors available | 12 |
| Max. capacity | 4 × 250 mL/ 2 × 5 MTP |
| Acceleration/braking ramps | 10/10 |
| Number of programs | 35 user-defined programs |
| Timer | 1 min to 99 min, with continuous run function, short-spin |
| Noise level | < 62 dB(A) |
| Power supply | 120 V, 50 – 60 Hz |
| Max. power consumption | 900 W |
| Dimensions (W × D × H) | 46.6 × 55.0 × 33.7 cm / 18.4 × 21.7 × 13.3 in |
| Footprint (dimensions w/o front panel, WxD) | 47 × 50 cm / 18.4 × 21.7 in |
| Product weight | 55 kg / 121.3 lb |
| Height (with open lid) | 74 cm / 29 in |
| Cooling | non-refrigerated |
| Temperature range | – |
