Agilent MSO7104A Mixed Signal Oscilloscope: 1 GHz, 4 analog plus 16 digital channels

Lab scope performance

• 1 GHz bandwidth
• 4 analog plus 16 digital channels
• 4 GSa/s sample rate
• Standard 8 Mpts MegaZoom III deep memory

Engineered for the best signal visibility

• 12.1” XGA display with 256 levels of intensity shows subtle signal detail
• Industry’s-fastest uncompromised update rate of up to 100,000 waveforms/sec displays infrequent events

Wide range of application packages

• I2C, SPI, CAN, LIN, RS-232/UART, and I2S
• Core-assisted FPGA debug for Xilinx and Altera devices
• Segmented memory
• PC-based offline analysis and viewing of previously acquired data

View online videos to see for yourself

• See the 7000 Series scopes in action video demo

Keysight’s InfiniiVision MSO7104A, equipped with a 12.1” XGA display, comes in a quiet package that is just 6.5” deep, and weighs only 13 pounds. With the world’s fastest uncompromised update rate, up to 100,000 waveforms per second, see subtle signal detail and infrequent events other scopes miss. A wide range of application packages provide rapid measurement insight.
